Specifications
| Product Name | ScanSnap iX100 | |
|---|---|---|
| General Technical Specifications | ||
| Scanner Type | CDF (Continuous Document Feeding), Simplex sheetfeed two-way paper path (Straight path, U-turn path) |
|
| Scanning Modes | Color, grayscale, monochrome, automatic (color / grayscale / monochrome detection) | |
| Image Sensor | CIS (Contact Image Sensor) x 1 | |
| Light Source | 3 Color LED (Red / Green / Blue) | |
| Optical Resolution | 600 dpi | |
| Scanning Speed (A4 portrait)(1) | Auto Mode(2) | 5.2 seconds / page |
| Normal Mode | 5.2 seconds / page | |
| Better Mode | 5.2 seconds / page | |
| Best Mode | 5.2 seconds / page | |
| Excellent Mode | 20.4 seconds / page | |
| Document Size(3) | Normal Mode | A4, A5, A6, B5, B6, Business Card, Post Card, Letter, Legal and Custom Size. Max: 216 X 360 mm (8.5 X 14.17 in.), Min: 25.4 x 25.4 mm (1 x 1 in.). Automatically recognizes document size. |
| Normal Mode with Carrier Sheet | Use of a Carrier Sheet permits the scanning of A3, B4, 279.4 x 431.8 mm (11 x 17 in.) and photographs as well as the document sizes listed above. | |
| Long Paper Scanning(4) | Max: 216 x 863 mm (8.5 x 34 in.) (300 dpi or less) | |
| Paper Weight (thickness) | 52.3 to 209.3 g/㎡, or 14 to 56 lb (Straight path) 52.3 to 80 g/㎡, or 14 to 20 lb (U-turn path) Card: Portrait or Landscape (Straight path) Non-embossed 0.76 mm or less Embossed: 0.76 + 0.48 mm (ISO7810 Conforming) |
|
| Paper Setting | Front-side up | |
| Continuous Scanning | 260 sheets (A4, color, simples, 300 dpi, battery operated)(8) | |
| Interface(5) | USB 2.0 (USB 1.1 compatible) | |
| Power Source | Li-ion Battery (3.7 V / 720 mAh) | |
| Power Requirement | 5 V / 0.5 A ( x 1port) | |
| Power Consumption(6) | During operation: 4.7 W or less During sleep mode: 2.2 W or less During Standby (OFF) mode: Less than 0.5 W |
|
| Operation Environment | Temperature | 5°C to 35°C (41°F to 95°F) |
| Relative Humidity | 20 to 80% (non-condensing) | |
| Dimensions (W x D x H)(7) | 273 x 47.5 x 36mm (10.74 x 1.87 x 1.42 in.) | |
| Device Weight | 400 g (0.88 lb) | |
| Environmental Compliance | ENERGY STAR® compliant/RoHS | |
| Driver | ScanSnap specific driver: • Windows®: Does not support Twain/ISIS® • Mac OS: Does not support Twain |
|
- Scanning speeds may vary due to the system environment used. Scanning speed measured from “start feeding document” to “finish output document” after pre-pick and pressing scan button (not including warm-up time). Warm-up time is less than 2 seconds (or less than 3 seconds from chute cover closed).
- Documents measuring approximately 148 mm in length or less are scanned in “Best mode”, while other documents are scanned in “Better mode”.
- Automatically stitch a two-page spread when scanning a folded A3, B4 or double letter size document one side at a time. The image is automatically stitched only if texts or diagrams cover across the two-page spread.
- ScanSnap iX100 is capable of scanning documents that exceed A4 size in length. This function is available for all models except for ‘Excellent mode’.
- Computer with USB 3.0 will work as USB 2.0 guaranteed only with USB cable provided with product.
- When operating with battery.
- When chute is closed.
- The number of sheets that can be scanned when connected to a computer via Wi-Fi with fully charged battery.
The number of sheets may vary due to the system environment used, usage method and repeated charging.
